ADL Embedded Solutions offers substitute for the Edison, Galileo and Joule series SBCs affected by Intel's announcement of discontinuation.

ADL Embedded Solutions offers substitute for the Edison, Galileo and Joule series SBCs affected by Intel's announcement of discontinuation.

10 July – ADL Embedded Solutions, a leading provider of high-performance embedded solutions, offers with Intel's BayTrail SoC series and its latest single board computers (SBC) the perfect substitute for developer boards of Intel's Edison, Galileo and J[…]

Read more

ADL Embedded Solutions offers substitute for the Edison, Galileo and Joule series SBCs affected by Intel's announcement of discontinuation.

ADL Embedded Solutions offers substitute for the Edison, Galileo and Joule series SBCs affected by Intel's announcement of discontinuation.
10 July – ADL Embedded Solutions, a leading provider of high-performance embedded solutions, offers with Intel's BayTrail SoC series and its latest single board computers (SBC) the perfect substitute for developer boards of Intel's Edison, Galileo and Joule series affected by the announcement of discontinuation.

Intel's end-of-life (EOL) announcement has surprised many customers involved with low power systems. Developers of typical applications such as mobile computing, wearables, IoT and IIOT are now anxious that they have opted for the wrong technology and their development efforts have been in vain. Furthermore, they are worried about a re-design that requires a great deal of efforts and expenses which delays their products' time to market. This is where ADL offers an instant solution with directly available hardware.

With the ADLE3800SEC, the PCIe/104-SBC ADLE3800PC and the 3.5 inch boards ADLE3800HD and ADLE3800HDC, ADL currently markets four solutions with x86 technology, which offer full Windows and Linux operating system compatibility. The SBCs boast high compute performance in addition to a broad graphics and interface offering and thus present the ideal solution for substituting the products affected by Intel’s discontinuation. Todays conducted developments based on x86 architecture can be continued 1:1 with the ADL hardware. This means that no resources are wasted and developments can continue without any major delays. The previous made investments were not wasted. Samples and development kits are available from ADL on a loan based option along with driver and firmware support (Windows and Linux).

"The ADLE3800SEC, a single board computer measuring just 75 x 75 mm and featuring Edge-Connect architecture, is based for example on processors from Intel's E3800 Atom family (BayTrail SoC product generation, later also Apollo Lake E39xx)", says Martin Kristof, Managing Director of ADL Embedded Solutions GmbH. "These processors are characterised by a TDP as low as 3 Watt for the Intel E3805 dual-core processor unitl up to only 10 Watt for the Intel E3845 quad-core processor. Thanks to this low power consumption and the wide input voltage range of the on-board PSU from 20 up to 30 VDC (optionally 7 up to 36 VDC), the SBC is easy to integrate in typical space constrained and mobile applications."

ADL Embedded Solutions offers a wide range of services to support developers. These include the design or the adaptation of fullcustom BIOS versions, the development of  custom-specific boards and cooling concepts. Integration support such as the installation of custom-specific operating systems are as well offered from the final assembly plant in Siegen. Not to mention the value-added services for rugged environmental usage like an optional BGA underfill and conformal coating for high shock and vibration resistance and/or deployment in harsh environments or in an extended temperature range. 3D CAD support with own ADL board models ensures matching enclosure and termal solution design.

The German design and development team of ADL Embedded Solutions is well experienced with customer-specific designs and support. All ADL boards are manufactured with state-of-the-art equipment at the EMS plant in Verl (North-Rhine Westphalia, Germany) in compliance with the highest quality standards. Perfect logistics ensures the production and assembly of the customers system and allows a just-in-time shipping.
On account of its global project experience in rugged embedded computers, ADL Embedded Solutions is the perfect partner for every industrial enterprise that depends on reliable solutions.



ADL Embedded Solutions Inc. Announces ADLQ170HDS 6th Generation Intel® Core™ Industrial 3.5” SBC

ADL Embedded Solutions Inc. Announces ADLQ170HDS 6th Generation Intel® Core™ Industrial 3.5” SBC

April 06, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, has announced today their latest high-performance industrial 3.5” Intel® Core™ single board computers (SBC). Based on 6th generation Intel Core S[…]

Read more

ADL Embedded Solutions Inc. Announces ADLQ170HDS 6th Generation Intel® Core™ Industrial 3.5” SBC

ADL Embedded Solutions Inc. Announces ADLQ170HDS 6th Generation Intel® Core™ Industrial 3.5” SBC
April 06, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, has announced today their latest high-performance industrial 3.5” Intel® Core™ single board computers (SBC). Based on 6th generation Intel Core Skylake processors and Intel’s Q170 chipset, the ADLQ170HDS provides a robust set of features with breakthrough performance-per-watt.

ADLQ170HDS features include 32 GB DDR4 DRAM, TPM 2.0, 4x SATA 6Gb/s, 4x USB 3.0, 4x PCIe X1, and much more. This makes it ideal for a variety of industrial applications where high-performance is an absolute necessity, but no less critical are less tangible features like high MTBF, long-life availability, hardware and firmware revision control, obsolescence management, technical, engineering and design support.

“Virtualization, high-speed and high-resolution vision systems, secure network appliances and high-speed storage are just a few of the target applications ideal for the ADLQ170HDS. Its rugged design and wide operating temperature range extends its use to include toll and border security, traffic engineering, alternative energy controllers and dataloggers, drone payload computing, and a variety of other use scenarios“, explains Martin Kristof, Managing Director of ADL Embedded Solutions GmbH.



ADL Embedded Solutions Inc. Announces New ADLMES9200 Rugged Chassis System

ADL Embedded Solutions Inc. Announces New ADLMES9200 Rugged Chassis System

March 27, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, has announced its latest rugged chassis system, the ADLMES9200. This suc[…]

Read more

ADL Embedded Solutions Inc. Announces New ADLMES9200 Rugged Chassis System

ADL Embedded Solutions Inc. Announces New ADLMES9200 Rugged Chassis System
March 27, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, has announced its latest rugged chassis system, the ADLMES9200. This successor to ADL’s popular ADLMES8200 rugged chassis is now IP67-rated with lower weight, lower cost and more reliable EMC-compliant gasket interfaces for robust military and rugged industrial applications.

Target markets for the ADLMES9200 include many of the traditional SWaP-constrained military/defense applications for mobile, tactical, airborne and ground vehicles. But also, rugged industrial applications in oil and gas, mining, construction, transportation and commercial unmanned vehicles. Designed to survive MIL-STD 810 rugged environments, the ADLMES9200 can suit the needs of a broad range of rugged use scenarios.

“Our ADLMES product line fulfills the need for quick-turn, rugged system enclosures for both production and low-volume development needs. The lower weight and cost of the ADLMES9200 system makes it a solid addition for ADL Embedded Solutions, Inc. and has already found early interest for GPR and rugged vision system design”, explains Martin Kristof, Managing Director of ADL Embedded Solutions GmbH.



ADL Debuts the Future of Embedded Solution Technology

ADL Debuts the Future of Embedded Solution Technology

March 02, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, will be showcasing brand new projects and prototypes of the next generation of embedded solutions at this year’s Embedded World.

The first[…]

Read more

ADL Debuts the Future of Embedded Solution Technology

ADL Debuts the Future of Embedded Solution Technology
March 02, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, will be showcasing brand new projects and prototypes of the next generation of embedded solutions at this year’s Embedded World.

The first prototype of ADL Embedded Solution’s ADLVIS-1700 CoaXPress/Cameralink Vision system will be debuted at Embedded World. The ADLVIS-1700 is the smallest CoaXPress system in the industry (HWD = 5” x 7” x 7.6”). The CoaXPress board inside the vision box is the first of its kind at the small PCIe/104 form factor. With 1200 MB per second camera transfer speed in a small form factor vision system, the ADLVIS-1700 helps address the need for high-performance image capture and storage in a variety of industries such as 3D machine vision, hyperspectral and multi-spectral imaging, traffic engineering, unmanned drone vision payload computing, and more. So far this speed and resolution has only been available on desktop PCs and larger devices. ADL has also included four removable SATA drives to accommodate the storage needs of this new technology as well as a single cable to provide power while sending data up to 300 feet.

Embedded World will also showcase the successor to ADL’s popular ADLMES8200 rugged chassis, the ADLMES9200. The ADLMES9200 is now IP67-rated with lower weight, lower cost and more reliable EMC-compliant gasket interfaces for robust military and rugged industrial applications. The IP67 allows the rugged device to not only survive water jets, but actually be underwater up to three feet for 30 minutes at a time. The lower weight will decrease fuel and battery costs while for mobile or unmanned applications such as drones, this means the drone or unmanned vehicle can stay operational for longer periods of time. Designed to survive MIL-STD 810 rugged environments the ADLMES9200 has military and defense applications but ADL also forsees industrial applications in oil and gasmining, construction, and transportation.

For an early look at Skylake, ADL’s new QM87HD Intel Core 6th Generation, stop by ADL’s booth at Embedded World to see an engineering sample. With hardware level TPM 2.0 encryption technology, the Skylake will combine security with powerful virtualization capabilities.

To see what’s new in embedded technology, visit ADL Embedded Solutions booth (#1-554, Hall 1) at the Embedded World Exposition & Conference in Nuremberg, Germany on March 14 - 16, 2017.



ADL Embedded Solutions, Inc. Announces ADLEPC-1500 Full-Featured, Ultra-Compact 3.4” x 3.2” Embedded PC

ADL Embedded Solutions, Inc. Announces ADLEPC-1500 Full-Featured, Ultra-Compact 3.4” x 3.2” Embedded PC

February 14, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, has announced today its ultra-compact ADLEPC-1500 Embedded PC. At 3.4” x 3.2”, the ADLEPC-1500 is a full-feature embedded PC targeted for unma[…]

Read more

ADL Embedded Solutions, Inc. Announces ADLEPC-1500 Full-Featured, Ultra-Compact 3.4” x 3.2” Embedded PC

ADL Embedded Solutions, Inc. Announces ADLEPC-1500 Full-Featured, Ultra-Compact 3.4” x 3.2” Embedded PC
February 14, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, has announced today its ultra-compact ADLEPC-1500 Embedded PC. At 3.4” x 3.2”, the ADLEPC-1500 is a full-feature embedded PC targeted for unmanned, Industrial controls, robotics, traffic management and surveillance. Its wide voltage and temperature range make it ideal for a variety of applications and environments.

The ADLEPC-1500 is based on the compact ADLE3800SEC E3800-series Atom SBC with onboard DisplayPort, USB3.0, USB2.0, M.2 KeyB 2242 SATA and two LAN ports. Quad and dual-core E3800 processor options also support DirectX 11, Open GL 4.0, and full HD video playback.

“This ultra-compact ADLEPC-1500 really resonates with embedded engineers in a variety of markets. Early interest and design wins include industrial printing, traffic monitoring, cyber security, security scanning and toll road or border camera applications,” explains Martin Kristof, Managing Director of ADL Embedded Solutions GmbH.



ADL Embedded Solutions Inc. Announces New 75mm x 75mm Intel E3800-series Edge-Connect SBC – ADLE3800SEC

ADL Embedded Solutions Inc. Announces New 75mm x 75mm Intel E3800-series Edge-Connect SBC – ADLE3800SEC

January 09, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, has announced today its compact ADLE3800SEC SBC with Edge-Connect. This ult[…]

Read more

ADL Embedded Solutions Inc. Announces New 75mm x 75mm Intel E3800-series Edge-Connect SBC – ADLE3800SEC

ADL Embedded Solutions Inc. Announces New 75mm x 75mm Intel E3800-series Edge-Connect SBC – ADLE3800SEC
January 09, 2017 - ADL Embedded Solutions Inc., a leading provider of high-performance embedded solutions, has announced today its compact ADLE3800SEC SBC with Edge-Connect. This ultra-compact 75mm x 75mm form factor is a full-featured, standalone SBC for rugged, embedded applications. The Edge-Connect architecture allows for added I/O expansion and connectors in a variety of baseboard/breakout board configurations (flat, vertical, odd-shapes, etc.) for rugged, portable/mobile applications such as unmanned systems, robotics, remote datalogging, wearable computing or portable medical devices.

At 75mm x 75mm the ADLE3800SEC is ideal for rugged, extended temperature intelligent systems with stringent size, weight, and power (SWAP) requirements. It boasts a wide thermal junction temperature (Tj) range (-40C to +85C), wide input voltage (20-30VDC), DisplayPort, USB2.0, USB3.0, and two GLAN ports with support for DirectX 11, Open GL 4.0, and full HD video playback.

“This rugged, ultra-compact SBC really seems to resonate with embedded engineers in a variety of markets. The early interest has been very positive with applications ranging from hand-held ground-penetrating radar applications to mobile location/navigation for port-of-entry systems, ATMs, toll road and border surveillance cameras and traffic management systems,” Martin Kristof, Managing Director of ADL Embedded Solutions GmbH.
